Milton 1100 ¼″ NPT Deluxe FRL Trio

Name: Milton 1100 ¼″ NPT Deluxe FRL Trio
Brand: Milton
SKU: 01B00068
Availability: InStock

Milton 1100 ¼″ NPT Deluxe FRL Trio integrates filter, regulator, and drip lubricator in a compact ¼″ NPT polycarbonate assembly—ideal for professional pneumatic setups.

SKU: 01B00068 Category: Industrial Supplies Tags: 1/4 NPT filter regulator lubricator, 150 psi FRL, 16 SCFM FRL trio, Milton 1100 ¼″ NPT Deluxe FRL Trio, polycarbonate FRL unit Brand: Milton

Description

Milton 1100 ¼″ NPT Deluxe FRL Trio is a premium, factory-assembled Filter-Regulator-Lubricator (FRL) unit designed to streamline air line conditioning for professional pneumatic systems. With integrated filter, regulator, and lubricator functions, the Milton 1100 ¼″ NPT Deluxe FRL Trio provides clean, regulated, and lubricated air—ensuring extended service life of tools and equipment.

The Milton 1100 ¼″ NPT Deluxe FRL Trio features a 40-micron polycarbonate filter element with automatic overnight drain, effectively removing moisture and particulates. A relieving-style regulator with a built-in gauge allows precise pressure control and easy monitoring. The drip-style lubricator meters oil into the line, reducing internal wear in air tools and valves.

Rated for 150 psi maximum pressure and delivering up to 16 SCFM of air flow at ¼″ NPT size, the Milton 1100 ¼″ NPT Deluxe FRL Trio is ideal for light to medium duty pneumatic applications—such as spray guns, impact wrenches, air brushes, and general workshop tools.

H2 Key Features

Filter: 40 µm polycarbonate element with auto drain
Regulator: Adjustable, relieving type with gauge
Lubricator: Drip-style with sight dome
Bowl Assembly: Durable polycarbonate with metal guards
Flow Rate: Up to 16 SCFM
Pressure Rating: 150 psi maximum
Thread Size: ¼″ NPT inlet/outlet

H2 Technical Specifications

Feature	Specification
Part Number	1100
Thread Type	¼″ NPT (national pipe thread)
Filter Element	40 µm polycarbonate with auto drain
Regulator Type	Relieving with pressure gauge included
Lubricator Type	Drip-style with adjustable oil feed
Max Operating Pressure	150 psi
Max Airflow	16 SCFM
Bowl Material	Polycarbonate with protective metal guard
Temperature Range	40 °F – 150 °F
Mounting	¼″ NPT bracket mountable
Origin	Made in USA
Weight	~1.8 lb / 0.82 kg

H2 Applications

The Milton 1100 ¼″ NPT Deluxe FRL Trio is suited for a variety of professional environments:

Automotive workshops (spray guns, impact tools)
Industrial machinery with air components
Construction and maintenance tool setups
Laboratory air systems
Pneumatic cleaning and instrumentation

H2 Installation & Maintenance

Use proper pipe sealant on ¼″ NPT threads
Securely mount using provided bracket
Adjust regulator to desired air pressure (align gauge)
Fill lubricator with light pneumatic oil
Drain filter bowl daily to prevent clogging
Replace filter element and seals annually or as needed

H2 Benefits

All-in-one FRL unit simplifies system builds
Factory-assembled for consistent performance
Auto-drain keeps air dry for tool protection
Polycarbonate bowl allows visual inspection
Metal guards enhance durability and safety
Compact and lightweight for easy install

H2 Why Choose Milton

Milton Industries is a trusted name in pneumatic equipment since 1943. The Milton 1100 ¼″ NPT Deluxe FRL Trio exemplifies their commitment to quality, reliability, and innovation—delivering a maintenance-friendly and professional-grade solution for air preparation.
